Micro service setup with Spring Cloud Netflix

June 17, 2017

There are many many ways how to set up a micro-service based application. The following article demonstrates how the Spring Cloud Netflix libraries can be used in order to build such an infrastructure. Besides the Spring stuff Hazelcast is taken as technology for session distribution.

flavor wheel

Following requirements are fulfilled:

  • Multiple instances of one micro-service can be deployed and requests will be load-balanced.
  • When one redundant micro-service fails, the overall application can continue working.
  • The overall application will be deployed on two servers.
  • When one server dies, the application can continue working on the remaining server.

Monitoring and other operational topics are not discussed in this article. All micro-services are assumed to be stateless. Persistence (database) is not considered here.

The shown setup is not limited to two servers. It can be extended easily to support multiple servers. Anyhow, in production it is not very likely that micro-services are deployed directly on a server. Rather e.g. Docker and Kubernetes or something alike will be used to provide an elastic and maintainable environment.

It is assumed a fail-safe edge service will be in place that provides load-balancing.

Schematic overview

The following diagram shows the connections that are established between the considered components.

Deployment structure

Components

Config server (Spring Cloud Config server)

The Spring Cloud Config server is used in order to support different environments. This server uses a git repository to store all configuration files. During start-up all micro-services request their configuration from that server which must run on a known URL which is basically the only information that must be stored statically in each micro-service.

Service discovery (Eureka)

The service discovery is an important building block and provided by Eureka. It provides information which service (serviceId) is running where (IP address and port).

The left Eureka is configured with the URL of the right Eureka server and vice versa so both servers connect to each other and share their information. Consequently, each Eureka instance knows about all running micro-services on both servers.

API gateway and load balancing (Zuul, Ribbon, Hystrix)

The API gateway is used to protect internal resources and allows mediation etc. to maintain compatibility. If one is not interested in these things, Zuul might not be required and the initial load balancing between the two servers is done by the external load balancer.

For load balancing Zuul can use Ribbon and Hystrix. While Ribbon provides the actual balancing Hystrix is the circuit breaker that ensures that Ribbon does not send requests to micro-services that do not respond as expected.

Micro services (Ribbon, Hystrix)

Each micro-service can be implemented straight-forwarding (or not) providing the required functionality. It may connect to a database e.g. using hibernate or whatever technology.

In order to be discoverable by other micro-services each micro-service must register with Eureka on start-up with its serviceId. In order to find other micro-services it will request this information from Eureka.

In this article it is assumed that MS-2 depends on MS-1 in order to provide its service. MS-1 does not depend on another service. Furthermore, it is assumed that only one MS-1 instance is deployed on each server and two instances of MS-2.

Although it is not necessary, it makes a lot of sense to use Feign for the communication within the micro-services. Feign makes use of Eureka in order to find other services by their serviceId. Besides that Feign is not related to the general setup and therefore is not discussed in this article.

In the same way as Zuul each micro-service uses Ribbon and Hystrix to load-balance requests to other micro-services. Since the two Eureka instances are connected to each other providing the information of all micro-services on both nodes the load-balancing also will use both servers. So, in case MS-1 (left) dies, the functionality of MS-2 (left) is not effected as it also uses both MS-1 (right) instances.

In this article it is assumed that Spring Security and Cookies are used for authentication matters. A micro-service connects as Hazelcast client to a Hazelcast node that is running on localhost.

Distributed Sessions (Hazelcast)

Hazelcast is not related to Spring Cloud but is supported by Spring Security and allows easy distribution of session information between different servers and effectively allows failover when one server dies.

The session service is configured with a list of all session services so that hazelcast is able to form the cluster.

It should also be possible to use the information about the available session services that is provided by Eureka. That is not supported out-of-the-box and I have not yet tried to implement this.

A different option could be to use JWT. Although JWT promises simplicity it might not be that simple as one could think.
